Thermometers

High quality thermometers for precise temperature measurement.

GMH 2710-T picture
GMH 2710-T Waterproof High Accuracy HACCP-Thermometer with Pt1000 General Purpose Probe

Application:
Accurate measurements for laboratories, quality management, and monitoring of production processes

Areas of application:
Foods (HACCP), medicine / pharmaceuticals, chemistry, fishkeeping, aquafarming, aquaculture

Specifications:

Measuring range: -199.0 ... +200.0 °C
Resolution: 0.1 °C
Accuracy: at -20.0 ... 100.0 °C ±0.1 °C ±1 digit
at -70.0 ... 200.0 °C ±0.1 % of meas. value ±2 digit

Probe: Pt1000, 2-wire, volt-free, water- and steam-proof, permanently connected to device, 135 mm long plastic handle, 1 m PVC cable (max 100 °C), Ø 3 mm / length: 100 mm
Response time T90: approx. 10 s
Display: two 4-digit LCD (12.4 mm and 7 mm)
Order code: 0190040095

GMH 2710-E picture
GMH 2710-E Waterproof High Accuracy HACCP-Thermometer with Pt1000 Insertion Probe

Application:
Accurate measurements for laboratories, quality management, and monitoring of production processes

Area of application:
Food (HACCP), medical / pharmaceutical science, chemistry, aquaristics, fish farming, aquaculture, etc.

Specifications:

Measuring range: -199.9 ... +200.0 °C
Resolution: 0.1 °C
Accuracy: at -20.0 ... 100.0 °C: ±0.1 °C ±1 digit
at -70.0 ... 200.0 °C: ±0.1 % of meas. value ±2 digit sensor calibrated together with device

Probe: plastic handle 135 mm long (max. 70 °C), additionally with slim insertion tip for all soft media. 1 m PVC cable (max 100 °C), Ø 3 mm / length: 100 mm
Response time T90: approx. 10 s
Display: two 4-digit LCD (12.4 mm and 7 mm)
Order code: 0190040258

GMH 2710-K picture
GMH 2710-K Waterproof HACCP-Thermometer (with Pt1000-probe-teflon probe and teflon cable for use with high temperatures up to 250°C)

Features:


High-precision measurements for:


Measuring range: -200.0 ... +200.0°C
Resolution: 0.1 °C
Accuracy: at -20.0 ... 100.0 °C ±0.1°C ±1 digit
at -70.0 ... 200.0 °C ±0,1 % v. MW. ±2 digit

Probe: Pt1000, 2-wire, potential-free, waterproof and steam-tight,
permanently connected to device, 3 mm diameter, 100 mm length,
Teflon handle and 1 m teflon cable. Handle and cable are resistant to permanent high temperatures up to 250°C. Stainless steel bend protection.
Reaction time T90: approx. 10 s
Display: two 4-digit LCD (12.4 mm and 7 mm)
Order code: 0190040096

GMH 2710-G picture
GMH 2710-G Waterproof HACCP-Thermometer (with Pt1000-probe-teflon probe and teflon cable for use with high temperatures up to 250°C)

Application:
Accurate measurements for laboratories, quality management, and monitoring of production processes

Area of application:
Food (HACCP), medical / pharmaceutical science, chemistry, aquaristics, fish farming, aquaculture, etc.

Specification:
Measuring range: -199.9 ... +250.0 °C
Resolution: 0.1 °C
Accuracy: at -20,0 ... 100,0 °C: ±0.1 °C ±1 digit
at -70.0 ... 200.0 °C: ±0.1 % of meas. value ±2 digit
sensor calibrated together with device

Probe: design type with small Teflon handle and 1 m Teflon cable, with slim insertion tip, handle and cable are suitable for permanent application at temperatures up to 250 °C. Stainless steel kink protection, Ø 1.5 mm / length: 100 mm
Response time T90: approx. 10 s
Display: two 4-digit LCD (12.4 mm and 7 mm)
Order code: 0190040259

GMH 2710-F picture
GMH 2710-F One-handed Temperature Measuring Device with Immersion Probe

Features:

Optimal for measurements at places difficult to access, e.g:


Measuring range: -70 ... +250 °C
Resolution: 0.1 °C
Accuracy:
- at -20.0 ... 100.0 °C: ±0.1 °C ±1 digit
- at -70.0 ... 200.0 °C: ±0.1 % of meas. value ±2 digit
- sensor calibrated together with device

Probe: V4A jacket tube, flexible, diameter: 3 mm / length: 150 mm
Response Time T90: approx. 10 s
Display: two 4-digit LCD (12.4 mm and 7 mm)
Order code: 0190040260

GMH 2170-I picture
GMH 2710-I One-handed Temperature Measuring Device with Insertion Probe

Features:

Optimal for measurements at places difficult to access, e.g:


Measuring range: -70 ... +250 °C
Resolution: 0.1 °C
Accuracy:
- at -20.0 ... 100.0 °C: ±0.1 °C ±1 digit
- at -70.0 ... 200.0 °C: ±0.1 % of meas. value ±2 digit
- sensor calibrated together with device

Probe: V4A jacket tube, with needle-shaped insertion tip, flexible, diameter: 3 mm / length: 150 mm
Response Time T90: approx. 10 s
Display: two 4-digit LCD (12.4 mm and 7 mm)
Order code: 0190040261

GTH 200 picture
GTH 200 Air Precision Air Temperature Thermometer

Features:

Fast and precise temperature measurements in:


Manufacturer: GHM Greisinger
Measuring range: -20.0 ... 70.0 °C
Resolution: 0.1 °C
Accuracy: (±1 digit) (at nominal temperature)
± 0.5% of meas. value ±0.1 °C

Sensor: Pt 1000, 1/3 DIN class B
Order code: 0190040249

GMH 175 picture
GMH 175 Precision Pt1000 Digital Thermometer

Manufacturer: GHM Greisinger
Measuring range: -199.9 to 199.9°C
Resolution: 0.1°C
Probe: Plug in Pt1000, 2 wire, 3.5mm jack connector
Features: battery/mains powered (via optional plug pack)
Order code: 0190040005

GMH 3710 picture
GMH 3710 High Precision Pt100 Thermometer

Features:


Manufacturer:
GHM Greisinger
Measuring range: -199.99 to 199.99°C or -200.0 to 850.0°C
Resolution: 0.01°C or 0.1°C
Probe: Plug in probe, Pt100, 4 wire, permanently connected
Accuracy of device: < ± 0.03°C at 0.01°C resolution
Analogue output: 0-1V, freely adjustable
Features: battery/mains powered (via optional plug pack)
Miscellaneous: Offset & slope adjustment, min/max memory, hold function, serial communications
Order code: 0190040118

GMH 3750 picture
GMH 3750 High Precision Pt100 Thermometer with Data Logger & Integrated Alarm

Features:

Manufacturer: GHM Greisinger
Measuring range: -199.99 to 199.99°C or -200.0 to 850.0°C
Resolution: 0.01°C or 0.1°C
Probe: Plug in probe, Pt100, 4 wire, permanently connected
Accuracy of device: < ± 0.03°C at 0.01°C resolution
Analogue output: 0-1V, freely adjustable
Measured value memory: 16,200
Features: battery/mains powered (via optional plug pack)
Miscellaneous: Offset & slope adjustment, min/max memory, hold function, serial communications
Order code: 0190040051

GMH 1150 picture
GMH1150 Digital Quick-Response Thermometer for Type K Thermocouple

Manufacturer: GHM Greisinger
Measuring Range: -50 °C...+1150 °C
Resolution: 1 °C
Plug-in Probe: NiCr-Ni (type K)
Features: battery/mains powered
Order code: 0190040067

GMH 1170 picture
GMH1170 Precision Quick-Response Thermometer for Type K Thermocouple

Manufacturer: GHM Greisinger
Measuring Range: -65.0...+199.9 °C or -65...+1150 °C
Resolution: 0.1 °C or 1 °C (0.1 °F or 1 °F)
Probe Connection: 2-pole standard flat-pin plug NiCr-Ni (type K)
Features: min./max. value memory, hold function, auto-off, offset/scale adjustable, battery/mains powered
Order code: 0190040016

GMH 3250 picture
GMH3250 Double / Difference / Quick Response Thermometer with Datalogger and Alarm

Manufacturer: GHM Greisinger
Measuring Range: -200... +1370 °C
Probe Connection:  J,K, N, S, T (thermocouples), 2 probes at the same time
Measured Value Memory: 99 manual, 5400 cyclic
Alarm: sounded via integrated buzzer
Miscellaneous: difference measurement, correction of measured value for surface measurements (on/off), min./max. value memory, hold function, battery/mains powered, zero-point offset entry, serial interface, can be connected to Easybus system
Order code: 0190040054

GMH 285-KB picture
GMH 285-KB Alarm Thermometer with 3.5 mm Jack Socket

Manufacturer: GHM Greisinger
Measuring range: -200.0 °C ... 400.0 °C
Resolution: 0.1 °C
Features: High precision, alarm, backlight and many other features characterize this device as a true all-rounder. The alarm function additionally allows for acoustic monitoring of the set temperature boundaries.
Application: Highly accurate measurements over a large measuring range in liquids, soft media, air/gases. Used for e.g. measurement in agriculture, quality control, laboratory, food production, etc.
Order code: 0190040257
